OBDSTAR MS50 Motorcycle Diagnostic Tool

R12,999.00

OBDSTAR MS50 Motorcycle Diagnostic Tool

The OBDSTAR MS50 Motorcycle Diagnostic Tool is a portable tablet which has super performance and industrial appearance design. It is a new generation of intelligent motorcycle diagnostic equipment tailored for customers. Based on RK3128 Quad-Core processor and equipped with a 5.0-inch capacitive touch screen, brings customer professional diagnosis experience.

ALL OBDSTAR PRODUCTS LINK: Https://Www.Diatools.Co.Za/Brand/Obdstar/

OBDSTAR MS50 Function Display:

1) Main Page/Brand Supported.

OBDSTAR MS50 Motorcycle Diagnostic Tool Display

Functions:

  1. New Android 5.1.1 operation system
  2. Simple and intuitive menu guidance allows you to quickly master the equipment operation;
  3. Provide complete diagnostic functions including code reading, code clearing, data flow, action test, setting, coding, etc.;
  4. Menu Arbitrary selection is more convenient and quicker;
  5. Record and play back real-time data streams, quickly and accurately locate sensor and component faults;
  6. Wi-Fi connection to the Internet, one-click software upgrade Via Official Website: Http://En.Obdstar.Com/
  7. One-Click remote function, OBDSTAR technical staff remote assistance;
  8. Support most of the Asia and Europe models;

Advanced function:

  1. The first fault guidance, help data, technical bulletin, diagnostic socket, etc. help you diagnose accurately and efficiently;
  2. Diversified data stream display modes namely as text, waveform diagram and instrument diagram, allowing you to easily analyze faults;
  3. Automatic scanning, automatic VIN recognition, control module programming and coding, ECU setting, instrument coding, tire pressure monitoring system, maintenance light reset, CO adjustment, idle speed adjustment, A/F value reset, ABS control unit setting, EOL mode, transmission memory reset, clear computer memory, etc.

OBDSTAR MS50 Motorcycle/snowmobile/ATV/UTV support car series:

Asia: Honda, Kawasaki, Kymco, Suzuki, SYM, Yamaha, PGO, Hardford, AEON.

OBDSTAR MS50 Motorcycle Diagnostic Tool Coverage 1

Europe: Benelli, KTM, Piaggio, Vespa.

OBDSTAR MS50 Motorcycle Diagnostic Tool Coverage 2

More functions under developing…

Different configurations include different software. For details, please contact OBDSTAR.

Help Data/Technical Bulletin/Fault Guidance:

OBDSTAR MS50 Motorcycle Diagnostic Tool Help Data 1

OBDSTAR MS50 Motorcycle Diagnostic Tool Help Data 2

OBDSTAR MS50 Supported System List/ Manual Service Function:

OBDSTAR MS50 Manual maintenance reset:

Diagnostic socket/Diag Connector Location:

Data Flow Text/ Waveform Diagram/Instrument Diagram:

Special Function-Benelli:

OBDSTAR MS50 Motorcycle Diagnostic Tool Benelli Special Functions 1

OBDSTAR MS50 Motorcycle Diagnostic Tool Benelli Special Functions 2

KTM Special Functions:

Piaggio Special Functions:

OBDSTAR MS50 Motorcycle Diagnostic Tool Piaggio Special Functions 1

OBDSTAR MS50 Motorcycle Diagnostic Tool Piaggio Special Functions 2

Vespa Special Functions:

OBDSTAR MS50 Motorcycle Diagnostic Tool Vespa Special Functions

OBDSTAR MS50 SPECIFICATIONS:

Operation system Android 5.1.1
CPU RK3128 Quad-Core ARM Cortex A7
Battery 2500mA, rechargeable polymer lithium battery
Extension memory card 32G Micro SD (TF) card supported
Storage capacity 16GB
LCD 5.0 inch
LCD resolution 800*600
Touch screen capacitive touch screen
Wifi supported
Working temperature -20℃  ~  55℃(14℉  ~  131℉ )
Storage temperature  -20℃  ~  70℃(-4℉  ~ 158℉ )
Weight about 700g
Dimension 140mm*89mm*18mm

OBDSTAR MS50 ACCESSORIES:

OBDSTAR MS50 Motorcycle Diagnostic Tool Package List 1

OBDSTAR MS50 Motorcycle Diagnostic Tool Package List 2

Brand

OBDSTAR

Weight 4.3 kg
Dimensions 45 × 34 × 14 cm
